Moto 372.7kWh C&I Energy Storage System
Home

C&I Bess Solution

Moto 372.7kWh C&I Energy Storage System

Moto 372.7kWh C&I Energy Storage System





Our LFP batteries offer high thermal stability with an IP66 protection level for outdoor applications. Designed with flexibility in mind, they are compatible with 600 - 1,500V systems, ensuring worry-free cooling with a separate water cooling system. CATL Battery with modular design with high energy density, ensure the safety and quality of the system and reduces floor space usage by 50% at the same time. Assembled for easy transportation, our batteries cut on-site installation costs and commissioning time, offering a reliable and efficient energy storage solution.

  • Cell Type :

    LiFePO4 (LFP)
  • Rated Voltage (V) :

    1331.2
  • Rated Capacity (Ah) :

    280
  • Rated Energy (kWh) :

    372.7
  • Dimension (mm) :

    2340*1300*1300
  • Connection :

    1P416S
  • Working Temp. (℃) :

    -25 ~ 55
  • Self-discharging Rate :

    ≤3% (25 °C, 50% SoC) Per Month
  • IP Rating :

    IP66
  • Scenario :

    Outdoor
  • Net Weight (KG) :

    3650±150
  • Communication :

    CAN
  • Certificate :

    IEC62619, UL1973, IEC61000, UN38.3
  • Calendar Life :

    15 Years (Working Condition 0.5 C @ 25 deg C, 80% DoD, 1 cycle per day)
  • Designed Cycle Life :

    3000 Cycles (0.5C/80%DOD/80%SOH/1 cycle per day)



IEC61000/IEC62040/IEC62619/CE/UN38.3/TUV







Modular design, more space-efficient.

Resistance up to C5 corrosion level, ensuring lifespan.

LFP batteries ensure system thermal stability

IP66 rating meets the requirements for outdoor applications of the battery.

CATL cells ensure both lifespan and overall efficiency

Flexible and easily expanded as per the requirements

Supports both on-grid and off-grid operations

Equip with cloud-based monitoring capabilities








  •

  •

  •
