Stock code : 600153.SH
C&D EMERGING ENERGY
12V 50A DCDC+MPPT Charger
Home

Energy Storage System

12V 50A DCDC+MPPT Charger

12V 50A DCDC+MPPT Charger
12V 50A DCDC+MPPT Charger
12V 50A DCDC+MPPT Charger
12V 50A DCDC+MPPT Charger
12V 50A DCDC+MPPT Charger
12V 50A DCDC+MPPT Charger
12V 50A DCDC+MPPT Charger
12V 50A DCDC+MPPT Charger

12V 50A DCDC+MPPT Charger



Meet the C&D Emerging Energy’s reliable mobile power solution. It is compatible with both traditional and smart generators, safeguarding the batteries of your vehicle while reaching up to 95% charging efficiency. With advanced charging logic, the charger improves performance for better energy management. From RVs to off-grid applications, this charger delivers the smart, stable energy you need — wherever you go.



Inquiry now



Certification



UL/PSE/FCC/CE/IEC





Features





  • Dual Charging Modes: Supports both DCDC and MPPT charging for flexible power input.
  • Wide Battery Compatibility: Suitable for lithium, lead-acid, gel, and other battery types.
  • Smart Chip Integration: Dynamically adjusts charging load in real-time for optimal performance.
  • Intelligent Temperature Control: Continuously monitors internal and external temperatures of both charger and battery to ensure safety and efficiency.





Not used "IGNTION” --Do not connect the ACC
CH3: Start Battery Original vehicle battery input channel Charging logic >12.5V charging starts after 5s
≤12.3V±0.1V stop charging		 >25V charging staris aiter 5s
≤24.6V±0.2V stop charging
Voltage range 12.5-16Vdc 25-32Vdc
Voltage system identification <17Vdc >17Vdc
Normal starting voltage >13.2Vdc >26.4Vdc
Overvoltage proteciion point >16.5V >32.5V
Overvoltage recovery point <16V <32V
Undervoltage protection point <12.3Vdc <24.6Vdc
Undervoltage recovery point >12.5Vdc >25Vdc
CH2:
Solar Aray
PV input
channel		 Voltage range 14.5-45Vdc
Undervoltage protection point <14.1Vdc
Undervoltage recovery point >14.5Adc
Overvoltage protection point >46V
Overvoltage recovery point <45V
MAX power <23V input.500W(MAX600W);
≥37.5-45V input,750W(MAX 800W)
CH1:
House Battery House Battery Channel		 Battery type AGM/GEL/FLOODED/LITHIUM
Output voltage 13.8-15.5Vdc, Typical value: 12v, Min: 8v
Overvoltage protection 16Vdc
Overvoltage recovery 15.5Vdc
Output current 5/10/15/20/25130135/40/45/50A
Output power 775W
Leakage current <50mA
Efficiency 95%
BTS Temperature detection Operating temperature description
No lithium battery, set to nor and disconnect the sensor
Remote Long-range CAN
Use "IGNITION"--connect the ACC
CH3:
Start Battery
Original vehicle battery input channel		 Parameter 12V 24V
Normal starting voltage >12V >24V
Charging logic >12.5V charging starts after 5s
≤11.8V±0.1V stop charging		 >24V charging starts after 5s
≤23.6V±0.2V stop charging
