Powerbox Pro Rack Mounted Lithium Battery

Powerbox Pro Rack Mounted Lithium Battery



Powerbox Pro | High-Performance Home Battery

C&D Emerging Energy Powerbox Pro Rack Mounted Lithium Battery is a cutting-edge low-voltage energy storage solution designed for modern households. Supporting up to 50 units in parallel, it provides scalable energy coverage from 10.24kWh to 512kWh, suitable for both small and large homes. Combining high protection, superior safety performance, easy installation, and a sleek, stylish design, the Powerbox Pro delivers reliable, high-performance, and expandable energy storage that perfectly fits the modern home.

Inquiry now

Series & Specification

Model Powerbox Pro
Battery Type LiFePO₄
Nominal Battery Energy 10.24 kWh
Operating Voltage 44.8-57.6V
Nominal Voltage 51.2V
Nominal Capacity 200Ah
Nominal Power 512kW
Peak Power 10.24kW
Recommended Charge & Discharge C Rate 0.5C
Recommended Charge/Discharge Current 100A
Recommended Depth of Discharge (DOD) 90%
Net Weight 103kg
Dimension[W/D/H] 555210928 mm
Charging Temp. Range 0--55°C
Discharging Temp. Range -20--55°C
Communication CAN/RS485
WiFi Module Optional
Cycle Life * >6000 Cycles
Protection Level IP65
Expansion ** Up to 50 units in parallel(This version is for production after September 2024)
Certification & Safety Standard UN38.3/CE-EMC/IEC62619/IEC62040/UKCA/CEC
Compatible Inverters Solis/Deye/Lupoower/Voltronic/Hoymiles/Growatt/Goodwe/SMA/Victron/Ingeteam/Delios/SAJ/APS etc.



* Test conditions: 0.2C Charging & Discharging, @25°C, 90% DOD

** World batteries are mixed with the new version, the quantity of new version batteries: Qty(new)=50-Qty(old)*2



Note: This specification is only suitable for Vietnam Market. Powerbox Pro is available for OEM/ODM orders.
